APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle

APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle

APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
  • APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle
Product Details:
Place of Origin: China
Brand Name: apollo
Model Number: rfn
Contact Now
Detailed Product Description
Displacement: / Max. Speed: > 80km/h
Battery: 74V / 2590 Kwh, LG Premium 21700 Lithium Cells Brakes: Front And Rear 4-piston Hydraulic Disc
Charging: 2-3 H With Quickcharge Function Controller: Sine Wave Controller
Waterproof: IP67 Electric Motor: Air Cooled Permanent Magnet Motor
Sprocket: 13-58T Rated Power: 5 KW
Peak Power: 12.5 KW Max Torque: 58 N.m Motor/270 N.m Wheel

Product Description
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 0
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 2
Specification

CITY RANGE

140
KM

PEAK POWER

12.5
KW

CRUB WEIGHT

70
KG

BATTERY

35
AH

SHOCK ABSORBERS

200
MM

TOP SPEED

60
KM/H
FULL SPECIFICATION
Battery
Capacity:
35Ah / 2590Wh
Cells:
LG Premium 21700 lithium cells
Features:
Removable, can be charged when installed in bike or separately.
Voltage (nominal):
74V
Brakes
Type:
Disc brakes, Four piston calipers, alloy levers. Hand lever for front- and rear brake.
Brake mode 1:
Motor brake with energy regeneration
Brake mode 2:
Freewheel, no motor brake
Drivetrain
Chain:
420 chain with DX
Electric motor:
Internal Rotor Permanent Magnet Synchronous Motor
Front sprocket:
11T
Rated power:
5kW
Peak power:
12.5kW
Rear sprocket:
58T
Torque (motor axle):
58 N·m
Torque (wheel):
305 N·m
Type:
Direct drive, chain
Dimensions
Fork angle:
24°
Ground clearence:
320mm - 12.60''
Offset:
15mm in triple clamps, 45mm in forks
Seat height:
860mm - 33.86''
Trail:
111mm - 4.37''
Wheel base:
1330mm - 52.36''
Suspension
Travel:
F 200mm R 75mm
Type:
F  Upside-down air forks featuring 45mm stanchion tubes for extra rigidity and strength, Double shoulder adjustable front damper.
R 240mm shock ,Compression damping / rebound damping adjustable + Spring preload adjustable.
Speed & Range
Range:
140 Km (Test data - Load: 75 Kg, 25 Km/h uniform speed, ambient temperature: 25 °C, flat pavement, standard tires, standard tire
pressure).
Top speed:
60km/h | 37.5mph
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 4
Certifications
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 6
Exhibition
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 8
Shipping & payment
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 10
FAQ
APOLLO RFN Ares Rally Pro Electric Motorcycle 74V 43AH 12.5KW Off Road 19inch Dirt Bike 74v 35ah Rfn Racing Motorcycle 12
1. who are we?
We are based in Jiangsu, China, start from 2019,sell to Eastern Europe(20.00%),South America(20.00%),North America(20.00%),Southern Europe(5.00%),Western Europe(5.00%),Northern Europe(5.00%),Eastern Asia(5.00%),Oceania(4.00%),Southeast Asia(4.00%),Mid East(3.00%),South Asia(3.00%),Africa(3.00%),Central America(3.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Electric Bike,Electric Bicycle,E-Bike,Bicycle,Ebike

4. why should you buy from us not from other suppliers?
1. Over ten-year experience in producing fitness equipments. 2. Strong manufacturing capacity, various kinds of products. 3. Professional foreign trade team. R&D team, multiple patent certificates. 4. Certified by CE & ISO 9001. 6. Quick delivery time

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DDP,DDU,Express Delivery,DAF;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,French,Russian,Korean,Italian
